Conn. Term. Input/Output Type Function
X55
1 NA
2 NA
3 Input Normally open, dry relay
contact
Closed for remote run with common
run/stop, close to run
4 Input
5 Input Normally closed, dry relay
contact
Safety input, open to stop
6 Input
7 NA
8 NA
9 NA
10 NA
11 Output Normally open, dry relay
contact
Closed indicates Motor 1 selected
12 Output
Conn. Term. Input/Output Type Function
X56
1 Output Normally open, dry relay
contact
Closed indicates Motor 2 selected
2 Output
3 Output Normally open, dry relay
contact
Closed when panel is in Drive Mode
4 Output
5 Output Normally open, dry relay
contact
Closed when panel is in Bypass Mode
6 Output
7 NA
8 NA
9 NA
10 Input Normally open, dry
contact
CMS Motor 2, close to select
11 Input Normally open, dry
contact
CMS common
12 Input Normally open, dry
contact
CMS Motor 1, close to select
Table 5.8 EMB1 Terminal Functions
Drive terminal
Parameter Value number Value name Function
18 5-10 Terminal 18 Digital
Input
8 Start Common run/stop
27 5-00 Digital I/O Mode 0 PNP External Interlock
27 5-01 Terminal 27 Mode 0 Input External Interlock
27 5-12 Terminal 27 Digital
Input
7 External Interlock External Interlock
Table 5.9 EMB1 Parameter Settings
Electromechanical Bypass (E... Option Panel Operating Instructions
MG14I102 - VLT
®
is a registered Danfoss trademark 37
5 5
