[86]
User define 6
[87]
User define 7
[88]
User define 8
8-43 PCD Read Configuration
Default value: [0] None
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Different parameters can be assigned to PCD 3–10 of the PPOs (the number of PCDs depends on the PPO type). PCD 3–10 hold the
actual data value of the selected parameters.
Table 195: Option:
[0]
None
[1]
[1500] Operation hours
[2]
[1501] Running hours
[3]
[1502] kWh counter
[4]
[1600] Control word
[5]
[1601] Reference [Unit]
[6]
[1602] Reference %
[7]
[1603] Status word
[8]
[1605] Main actual value [%]
[9]
[1609] Custom readout
[10]
[1610] Power [kW]
[11]
[1611] Power [hp]
[12]
[1612] Motor voltage
[13]
[1613] Frequency
[14]
[1614] Motor current
[15]
[1615] Frequency [%]
[16]
[1618] Motor thermal
[17]
[1630] DC link voltage
[18]
[1634] Heatsink temp.
[19]
[1635] Inverter thermal
[20]
[1638] SL controller state
[21]
[1650] External teference
[22]
[1652] Feedback [Unit]
[23]
[1660] Digital input 18, 19, 27, 33
[24]
[1661] Terminal 53 switch setting
