8-42 PCD Write Configuration
Default value: [0] None
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Different parameters can be assigned to PCD 3–10 of the PPOs (the number of PCDs depends on the PPO type). The values in PCD
3–10 are written to the selected parameters as data values.
Table 194: Option:
[0]
None
[1]
[302] Minimum reference
[2]
[303] Maximum reference
[3]
[341] Ramp 1 ramp up time
[4]
[342] Ramp 1 ramp down time
[5]
[351] Ramp 2 ramp up time
[6]
[352] Ramp 2 ramp down time
[7]
[380] Jog ramp time
[8]
[381] Quick stop time
[9]
[412] Motor speed low limit [Hz]
[10]
[414] Motor speed high limit [Hz]
[11]
[590] Digital & relay bus control
[12]
[676] Terminal 45 output bus control
[13]
[696] Terminal 42 output bus control
[14]
[894] Bus feedback 1
[15]
FC port CTW
[16]
FC port REF
[17]
[2021] Setpoint1
[18]
[311] Jog speed [Hz]
[21]
[553] Term. 29 high ref./feedb. value
[22]
[615] Terminal 53 high ref./feedb. value
[23]
[625] Terminal 54 high ref./feedb. value
[24]
[895] Bus feedback 2
[81]
User define 1
[82]
User define 2
[83]
User define 3
[84]
User define 4
[85]
User define 5
