16-37 Inv. Max. Current
Change during operation: True
View the inverter maximum current. The data is used for calculation of drive protection and so on.
Table 318: Range:
N O T I C E
The maximum display value is 655.35 A, if the actual drive inverter maximum current surpasses 655.35 A, the data can be viewed
from parameter 18-87 Inv. Max. Current.
16-38 SL Controller State
Change during operation: True
View the actual state of the smart logic controller (SLC).
Table 319: Range:
4.13.4 16-5* Ref. & Feedb.
16-50 External Reference
Change during operation: True
View the total reference, the sum of digital, analog, preset, bus, and freeze references.
Table 320: Range:
16-52 Feedback[Unit]
Default value: 0 ProcessCtrlUnit
Change during operation: True
View the feedback resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maximum Refer-
ence.
Table 321: Range:
Max: 4999 ProcessCtrlUnit
Default value: 0 ProcessCtrlUnit
16-54 Feedback 1 [Unit]
Default value: 0 ProcessCtrlUnit
Change during operation: True
View the feedback 1 value resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maxi-
mum Reference and selection of unit in parameter 20-12 Reference/Feedback Unit.
