Table 322: Range:
Min: -999999.999
Max: 999999.999 ProcessCtrlUnit
Default value: 0 ProcessCtrlUnit
16-55 Feedback 2 [Unit]
Default value: 0 ProcessCtrlUnit
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: False
View the feedback 2 value resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maxi-
mum Reference and selection of unit in parameter 20-12 Reference/Feedback Unit.
Table 323: Range:
Min: -999999.999
Max: 999999.999 ProcessCtrlUnit
Default value: 0 ProcessCtrlUnit
16-56 Feedback 3 [Unit]
Default value: 0 ProcessCtrlUnit
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: False
View the feedback 3 value resulting from the selection of scaling in parameter 3-02 Minimum Reference and parameter 3-03 Maxi-
mum Reference and selection of unit in parameter 20-12 Reference/Feedback Unit.
Table 324: Range:
Min: -999999.999
Max: 999999.999 ProcessCtrlUnit
Default value: 0 ProcessCtrlUnit
4.13.5 16-6* Inputs and Outputs
16-60 Digital Input
Default value: 0
Parameter type: Range
2-setup: 1 setup
Conversion index: 0
Data type: u_int16
Change during operation: True
View actual state of the digital inputs.
Table 325: Bit Definitions
Bit 0
Unused
Bit 1
Unused
Bit 2
Digital input terminal 29
Bit 3
Digital input terminal 27
Bit 4
Digital input terminal 19
Bit 5
Digital input terminal 18
Bit 6–15
Unused
Table 326: Range:
Min: 0
Max: 4095
Default value: 0
16-61 Terminal 53 Setting
Default value: [0] Current mode
Parameter type: Option
2-setup: 1 setup
Conversion index: -
Data type: u_int8
Change during operation: True
View the setting of input terminal 53.
AU363928304090en-000101 / 130R0982 | 151Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
