Set output speed used for registration of no-flow power at low speed.
Table 391: Range:
22-34 Low Speed Power [kW]
Change during operation: True
Set no-flow power at low speed.
Table 392: Range:
22-37 High Speed [Hz]
Change during operation: True
Set output speed used for registration of no-flow power at high speed.
Table 393: Range:
22-38 High Speed Power [kW]
Change during operation: True
Set no-flow power at high speed.
Table 394: Range:
4.16.3.1 No-flow Power Tuning Sequence
N O T I C E
Set parameter 1-03 Torque Characteristics before tuning takes place.
Procedure
To stop flow, close the main valve.
Run with motor until the system has reached normal operating temperature.
Press the [Hand On] key on the LCP and adjust speed for approximately 85% of the rated speed. Note the exact speed.
Read power consumption either by looking for actual power in the data line in the LCP or call parameter 16-10 Power [kW] in
the Main Menu. Note the power readout.
Change speed to approximately 50% of the rated speed. Note the exact speed.
Read power consumption either by looking for actual power in the data line in the LCP or call parameter 16-10 Power [kW] in
the Main Menu. Note the power readout.
Program the speeds used in parameter 22-33 Low Speed [Hz] and parameter 22-37 High Speed [Hz].
Program the associated power values in parameter 22-34 Low Speed Power [kW] and parameter 22-38 High Speed Power [kW].
Switch back pressing [Auto On] or [Off].
AU363928304090en-000101 / 130R0982 | 169Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
