24-03 Fire Mode Min Reference
Default value: 0 FireModeUnit
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
The minimum reference is the lowest value obtainable by summing the references. The minimum reference value and unit matches
the choice of configuration in parameter 1-00 Configuration Mode and the unit in parameter 20-12 Reference/Feedback Unit.
Table 425: Range:
Min: -4999.0
Max: 4999.0 FireModeUnit
Default value: 0 FireModeUnit
24-04 Fire Mode Max Reference
Default value: 50.000 FireModeUnit
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
The maximum reference is the highest value obtainable by summing all references. The maximum reference value and unit matches
the choice of configuration in parameter 1-00 Configuration Mode and the unit in parameter 20-12 Reference/Feedback Unit.
Table 426: Range:
Min: -4999.0
Max: 4999.0 FireModeUnit
Default value: 50.000 FireModeUnit
24-05 FM Preset Reference
Default value: 0%
Parameter type: Range
2-setup: All setups
Conversion index: 0
Data type: int16
Change during operation: True
Enter the required preset reference/setpoint as a percentage of the fire mode maximum reference set in Hz.
Table 427: Range:
Min: -100%
Max: 100%
Default value: 0%
24-06 Fire Mode Reference Source
Default value: [0] No function
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Table 428: Option:
[0]
No function
[1]
Analog input 53
[2]
Analog input 54
[7]
Pulse input 29
24-07 Fire Mode Feedback Source
Default value: [0] No function
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
This parameter defines which input on the drive should be treated as the source of the feedback signal.
Table 429: Option:
[0]
No function
[1]
Analog input 53
AU363928304090en-000101 / 130R0982180 | Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
