The jog speed is a fixed output speed at which the drive runs when the jog function is activated. See also parameter 3-80 Jog Ramp
Time.
Table 100: Range:
3-14 Preset Relative Reference
Change during operation: True
Define the fixed value in % to be added to the variable value defined in parameter 3-18 Relative Scaling Reference Resource.
The sum of fixed and variable values (labeled Y in the following illustration) is multiplied by actual reference (labeled X in the follow-
ing illustration). This product is added to actual reference:
X + X ×
Y
100
Relative
Z=X+X*Y/100
Resulting
actual
reference
Y
X
e30ba059.13
Z
Illustration 10: Preset Relative Reference
Table 101: Range:
3-15 Reference 1 Source
Default value: [1] Analog Input 53
Change during operation: True
Select the input to be used for the 1
st
reference signal. Parameter 3-15 Reference 1 Source, parameter 3-16 Reference 2 Source, and
parameter 3-17 Reference 3 Source define up to 3 different reference signals. The sum of these reference signals defines the actual
reference.
Table 102: Option:
3-16 Reference 2 Source
Default value: [2] Analog Input 54
Change during operation: True
Select the input to be used for the 2
nd
reference signal. Parameter 3-15 Reference 1 Source, parameter 3-16 Reference 2 Source, and
parameter 3-17 Reference 3 Source define up to 3 different reference signals. The sum of these reference signals defines the actual
reference.
