4.6.3 4-5* Adj. Warnings
Define adjustable warning limits for current. Warnings are shown on the display, programmed output, or fieldbus.
4-50 Warning Current Low
Default value: 0 A
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int32
Change during operation: True
Enter the I
LOW
value. When the motor current drops below this limit, a bit in the status word is set. This value can also be program-
med to produce a signal on the digital output or the relay output.
Table 118: Range:
Min: 0 A
Max: 500 A
Default value: 0 A
4-51 Warning Current High
Default value: Configuration dependent
Parameter type: Range
2-setup: All setups
Conversion index: -2
Data type: u_int32
Change during operation: True
Enter the I
HIGH
value. When the motor current exceeds this limit, a bit in the status word is set. This value can also be programmed to
produce a signal on the digital output or the relay output.
Table 119: Range:
Min: 0.0 A
Max: 500.00 A
Default value: Configuration dependent
4-54 Warning Reference Low
Default value: -4999
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
Enter the lower reference limit. When the actual reference drops below this limit, the display indicates Ref
Low
. Warning bit 20 is set
in parameter 16-94 Ext. Status Word. The output relay or the digital output can be configured to indicate this warning. The LCP warn-
ing indicator light is not turned on when this parameter set limit is reached.
Table 120: Range:
Min: -4999
Max: 4999
Default value: -4999
4-55 Warning Reference High
Default value: 4999
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
Use this parameter to set a higher limit for the reference range. When the actual reference exceeds this limit, the display reads Refer-
ence High. Warning bit 19 is set in parameter 16-94 Ext. Status Word. The output relay or the digital output can be configured to
indicate this warning. The LCP warning indicator light is not turned on when this parameter set limit is reached.
Table 121: Range:
Min: -4999
Max: 4999
Default value: 4999
4-56 Warning Feedback Low
Default value: -4999.000
Parameter type: Range
2-setup: All setups
Conversion index: -3
Data type: int32
Change during operation: True
Use this parameter to set a lower limit for the feedback range. When the feedback drops below this limit, the display reads Feedback
Low. Warning bit 6 is set in parameter 16-94 Ext. Status Word. The output relay or digital output can be configured to indicate this
warning. The LCP warning indicator light is not turned on when this parameter set limit is reached.
AU363928304090en-000101 / 130R098266 | Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
