5-01 Terminal 27 Mode
Default value: [0] Input
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Table 129: Option:
[0]
Input
Define terminal 27 as a digital input.
[1]
Output
Define terminal 27 as a digital output.
5-02 Terminal 29 Mode
Default value: [0] Input
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Table 130: Option:
[0]
Input
Define terminal 29 as a digital input.
[1]
Output
Define terminal 29 as a digital output.
5-03 Digital Input 29 Mode
Default value: [0] PNP
Parameter type: Option
2-setup: 1 setup
Conversion index: -
Data type: u_int8
Change during operation: False
Table 131: Option:
[0]
PNP
Set to PNP mode for digital inputs 29.
[1]
NPN
Set to NPN mode for digital inputs 29.
4.7.2 5-1* Digital Inputs
Parameters for configuring the input functions for the input terminals. The digital inputs are used for selecting various functions in
the drive.
Table 132: Selected Preset Reference (Parameter 3-10 Preset Reference)
Selected preset reference:
Preset reference bit 2
Preset reference bit 1
Preset reference bit 0
Preset reference 0
0
0
0
Preset reference 1
0
0
1
Preset reference 2
0
1
0
Preset reference 3
0
1
1
Preset reference 4
1
0
0
Preset reference 5
1
0
1
Preset reference 6
1
1
0
Preset reference 7
1
1
1
