Table 169: Option:
[0]
Current mode
[1]
Voltage mode
4.8.4 6-7* Analog/Digital Output 45
Parameters for configuring the scaling and limits for analog/digital output terminal 45. Analog outputs are current outputs: 0/4–
20 mA. Resolution on analog output is 12 bit. Analog output terminals can also be set up as digital output.
6-70 Terminal 45 Mode
Default value: [0] 0-20 mA
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Set terminal 45 to act as analog output or as digital output.
Table 170: Option:
[0]
0-20 mA
[1]
4-20 mA
[2]
Digital Output
6-71 Terminal 45 Analog Output
Default value: [0] No operation
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Select the function of terminal 45 as an analog current output. See also parameter 6-70 Terminal 45 Mode.
Table 171: Option:
[0]
No operation
[100]
Output frequency
[101]
Reference
[102]
Feedback
[103]
Motor Current
[106]
Power
[139]
Bus Control
[254]
DC Link Voltage
6-72 Terminal 45 Digital Output
Default value: [0] No operation
Parameter type: Option
2-setup: All setups
Conversion index: -
Data type: u_int8
Change during operation: True
Select the function of terminal 45 as a digital current output. See also parameter 6-70 Terminal 45 Mode. See parameter 5-40 Function
Relay for description of the options.
Table 172: Option:
[0]
No operation
[1]
Control Ready
AU363928304090en-000101 / 130R098296 | Danfoss A/S © 2021.07
Parameters
VLT® Flow Drive FC 111
Programming Guide
