Danfoss VLT HVAC Drive User Manual

Data storage in LCP:
1. Go to par. 0-50
LCP Copy
2. Press the [OK] key.
3. Select “All to LCP”
4. Press the [OK] key.
All the parameter settings are now stored in the GLCP as indicated by the progress bar. When
100% is reached, press [OK].
The GLCP can now be connected to another adjustable frequency drive, and the parameter set-
tings can be copied to this adjustable frequency drive.
Data transfer from LCP to adjustable frequency drive:
1. Go to par. 0-50
LCP Copy
2. Press the [OK] key.
3. Select “All from LCP.”
4. Press the [OK] key.
The parameter settings stored in the GLCP are now transferred to the adjustable frequency drive,
as indicated by the progress bar. When 100% is reached, press [OK].
VLT
®
HVAC Drive Instruction Manual
5. How to operate the adjustable frequency
drive
MG.11.A4.22 - VLT
®
is a registered Danfoss trademark 61
5

Danfoss VLT HVAC Drive Specifications

General

Type	VLT HVAC Drive
STO (Safe Torque Off)	Yes
Enclosure	IP20
Output Frequency	0-500 Hz
Brake Chopper	Built-in (depending on frame size)
EMC Filter	Built-in (depending on frame size)
Communication	Ethernet
Power Range	0.37 kW to 630 kW
Input Voltage	200-240V, 380-480V, 525-600V
Protection Features	Overload, Overvoltage, Undervoltage, Short Circuit, Ground Fault
Ambient Temperature	-10°C to +50°C (with derating above +40°C)
Storage Temperature	-25°C to +70°C
Relative Humidity	5-95% (non-condensing)
Cooling Method	Air-cooled
