Danfoss VZH Series Application Guidelines

Application guidelines
10 FRCC.PC.023.A7.22
Single compressorsTechnical specications
Capacity at EN12900 rating conditions - High pressure ratio - VZH088AJ - VZH117AJ - VZH170AJ
Models
rpm
Freq (Hz)
Te -13 -10 0 10 20 30 40 50 59
Tc Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe Qo Pe
VZH088AJ
1500
25
70 - - - - 19800 1.57 24800 1.66 30800 1.73 37900 1.75 46100 1.65 - - - -
90 - - - - 17500 2.21 22300 2.18 28000 2.21 34500 2.25 42100 2.24 50700 2.14 59500 1.91
110 - - - - 15000 3.22 19500 3.02 24600 2.95 30600 2.95 37300 2.97 45000 2.96 52900 2.88
130 - - - - - - - - 20500 4.03 25600 3.94 31500 3.93 38200 3.96 44900 3.97
140 - - - - - - - - - - 22700 4.57 28100 4.53 34200 4.55 40300 4.59
145 - - - - - - - - - - - - - - - - - -
3600
60
70 37500 4.35 40200 4.38 50300 4.46 62600 4.55 77200 4.66 94500 4.79 114600 4.95 - - - -
90 32100 5.36 34700 5.38 44200 5.46 55500 5.54 69000 5.64 84800 5.75 103200 5.89 124600 6.05 146400 6.23
110 - - - - 38300 6.81 48500 6.87 60500 6.94 74600 7.03 91000 7.14 110100 7.27 129600 7.41
130 - - - - - - - - 51000 8.77 63100 8.82 77300 8.89 93800 8.98 110800 9.07
140 - - - - - - - - - - 56700 9.97 69600 10.01 84700 10.07 100400 10.14
145 - - - - - - - - - - - - 61300 11.32 74900 11.36 89200 11.40
6000
100
70 - - - - 82300 8.06 102300 8.42 126300 8.84 154800 9.34 188000 9.92 - - - -
90 - - - - 73500 9.67 92200 9.94 114400 10.26 140500 10.64 171000 11.08 206200 11.62 242300 12.18
110 - - - - 64600 11.85 81400 12.02 101200 12.23 124400 12.48 151500 12.78 182800 13.16 215000 13.57
130 - - - - - - - - 85700 15.01 105400 15.12 128500 15.27 155400 15.48 183200 15.72
140 - - - - - - - - - - 94600 16.82 115500 16.90 139900 17.02 165200 17.17
145 - - - - - - - - - - - - - - - - - -
VZH117AJ
1500
25
70 - - - - 26500 2.07 33300 2.17 41400 2.28 50900 2.30 61900 2.17 - - - -
90 - - - - 23500 2.90 29900 2.86 37500 2.91 46300 2.96 56500 2.95 68100 2.81 79900 2.51
110 - - - - 20200 4.23 26200 3.97 33100 3.87 41000 3.88 50100 3.91 60500 3.89 71000 3.79
130 - - - - - - - - 27500 5.30 34400 5.17 42300 5.17 51200 5.20 60300 5.21
140 - - - - - - - - - - 30500 6.00 37700 5.95 45900 5.98 54200 6.02
145 - - - - - - - - - - - - - - - - - -
3600
60
70 50400 5.72 54000 5.75 67500 5.85 84000 5.97 103600 6.12 126800 6.29 153900 6.50 - - - -
90 43100 7.04 46500 7.07 59300 7.17 74500 7.27 92600 7.40 113800 7.55 138600 7.73 167200 7.95 196500 8.18
110 - - - - 51400 8.94 65100 9.02 81200 9.12 100100 9.24 122200 9.38 147800 9.55 174000 9.73
130 - - - - - - - - 68500 11.52 84700 11.59 103800 11.67 125900 11.79 148700 11.92
140 - - - - - - - - - - 76100 13.09 93400 13.15 113700 13.23 134700 13.32
145 - - - - - - - - - - - - 82200 14.87 100600 14.91 119700 14.98
6000
100
70 - - - - 110500 10.59 137300 11.06 169600 11.62 207800 12.27 252400 13.03 - - - -
90 - - - - 98700 12.70 123700 13.06 153600 13.47 188600 13.97 229500 14.56 276800 15.26 325300 16.00
110 - - - - 86700 15.56 109200 15.79 135800 16.06 167000 16.39 203300 16.79 245400 17.28 288600 17.82
130 - - - - - - - - 115000 19.71 141500 19.86 172500 20.06 208600 20.33 245900 20.65
140 - - - - - - - - - - 126900 22.10 155000 22.19 187800 22.35 221800 22.56
145 - - - - - - - - - - - - - - - - - -
VZH170AJ
1500
25
70 - - - - 40800 3.23 50600 3.21 62400 3.17 76300 3.06 92500 2.83 - - - -
90 - - - - 35700 4.30 45000 4.25 55900 4.24 68800 4.24 83700 4.19 101000 4.05 118700 3.80
110 - - - - 30100 5.80 38400 5.61 48200 5.53 59700 5.52 73000 5.54 88500 5.53 104300 5.47
130 - - - - - - - - 39200
7.31 48900 7.19 60300 7.15 73600 7.17 87300 7.19
140 - - - - - - - - - - 42800 8.25 53100 8.15 65200 8.13 77700 8.15
145 - - - - - - - - - - - - - - - - - -
3600
60
70 76400 7.78 81200 7.83 99800 8.03 122700 8.23 150500 8.41 183900 8.53 223200 8.55 - - - -
90 66500 10.06 71100 10.07 88700 10.18 110200 10.34 135900 10.53 166600 10.70 202700 10.83 244700 10.89 288100 10.84
110 - - - - 78000 13.02 97200 13.06 120100 13.18 147300 13.33 179300 13.50 216700 13.63 255500 13.70
130 - - - - - - - - 101500 16.56 124500 16.62 151700 16.73 183800 16.87 217200 16.99
140 - - - - - - - - - - 111400 18.56 135900 18.62 165000 18.73 195500 18.84
145 - - - - - - - - - - - - 118500 20.72 144400 20.78 171800 20.88
6000
100
70 - - - - 164400 14.09 204200 14.78 252100 15.56 308900 16.50 375400 17.67 - - - -
90 - - - - 144600 17.58 181500 18.20 225300 18.81 276900 19.47 337200 20.25 407100 21.22 478800 22.31
110 - - - - 127700 21.86 160900 22.52 200000 23.06 245800 23.55 299200 24.04 361000 24.61 424600 25.25
130 - - - - - - - - 171900 28.55 211200 28.96 257000 29.27 310100 29.55 364900 29.83
140 - - - - - - - - - - 191300 32.24 233000 32.50 281500 32.67 331700 32.81
145 - - - - - - - - - - - - - - - - - -
To: Evaporating temperature in °F Superheat = 10 K Presented data are for models with motor voltage code J
Tc: Condensing temperature in °F Subcooling = 0 K
Qo: Cooling capacity in Btu Pe: Power input in kW
