Danfoss VZH Series Application Guidelines

Application guidelines
25FRCC.PC.023.A7.22
Single compressorsDimensions
VZH117-J manifolded versionVZH117-J single version
0.59 inch
HM 8 bolt
Lock washer
Flat washer
Steel mounting
sleeve
Rubber grommet
Nut
Ø 1.59” hole
Ø 0.65”
knockout
Power supply
Grommet
All dimensions in inch
Electrical box
4 hole
Ø 0.75
0.57 with
compression
9.05
30°
30°
60°
9.05
7.5
7.5
7.91
Ø8.82
Ø8.69
Ø9.57
20.75
max.
6.18
5.47
3.37
7.16
6.06
7.89
Discharge
7/8"
Suction
1"3/8
19.43
10.33
Ø8.82
Ø8.69
Ø9.57
oil equalisation
Ø32 - 1.75" -
12 UN - 2A
4 hole
Ø 0.75
6.18
5.47
2.27
3.37
10.33
19.43
Discharge
7/8"
Suction
1"3/8
7.16
0.57 with
compression
9.05
7.89
6.06
6.71
30°
30°
60°
9.05
7.5
7.5
20.75
max.
