Application guidelines
85FRCC.PC.023.A7.22
Manifold compressors
Ordering information
Ordering information
Mounting kit for rubber
connection
Manifolding kit 24V Type
To build a complete tandem, customers must
order 2 compressors and 1 manifolding kit
and 1 mounting kit(for VZH170 hybrid rubber
connection). Manifolding kit selection should
base on compressor models and oil level switch
voltage.
Please note for VZH170 hybrid manifolding,
rigid spacers is delivered with compressor
SH180/240/295 please leave rigid connection
when rubber connection is adopted.
For rubber connection:
· VZH088:1FS+1VS+1new manifolding kit
· VZH117:1FS+1VS+1new manifolding kit
· VZH170: 1FS+1VS+1new manifolding kit+1
rubber mounting kit(8156138)
Ordering example:
VZH170AGBNB+SH180 code 4, 24V type:
· Rubber grommet solution:
· 1x VZH170(120G0030)+1x SH180(120H0267)
+1 x new manifolding kit(120Z0591)+1x
rubber mounting kit(8156138)
Danfoss VZH and SH scroll compressors can
be ordered in either industrial packs or in
single packs. Please refer to single compressor
application guideline for ordering. The tandem
kits can be ordered with code numbers from
below table.
Note: rubber mounting kit for manifolding is the same as single
compressor mounting kit.
Hybrid VZH088/117 VZH170
No Code number 120Z0066 8156138
14 grommet 4 4
15 sleeve 4 4
16 bolt 4 4
17 washers 4 4
24VAC/
VDC type
Code Number
New code number 120Z0586 120Z0587 120Z0588 120Z0589 120Z0590 120Z0591 120Z0592 120Z0593
No Description
VZH088+
SH090
VZH088+
SH120
VZH117+
SH140
VZH117+
SH161
VZH117+
SH184
VZH170+
SH180
VZH170+
SH240
VZH170+
SH295
1 Oil level monitor-Electrical part 1 1 1 1 1 1 1 1
2 Organ pipe Nelico 2 2 2 2 2
3 Sleeve 1 1/8" 2 2 2 2 2
4 Sleeve 1 3/8" 2 2 2
5 Teon gasket 1 1/8" 2 2 2 2 2
6 Teon gasket 1 3/8" 2 2 2
7 Restrictor VZH088+SH090 1
8 Restrictor VZH088+SH120 1
9 Restrictor VZH117+SH140/VZH117+SH161 1 1
10 Restrictor VZH117+SH184 1
11 Restrictor VZH170+SH180 1
12 Restrictor VZH170+SH240 1
13 Rigid spacer 7mm 4 4
