Danfoss VZH Series Application Guidelines

Application guidelines
36 FRCC.PC.023.A7.22
Single compressorsElectrical data, connections and wiring
Fuses / circuit breakers Danfoss recommends using the fuses/circuit
breakers listed below to protect service
personnel and property in case of component
break-down in the frequency converter. For
circuit breakers, Moeller types have been tested
and are recommended. Other types of circuit
breakers may be used provided they limit the
energy to a level equal to or lower than the
Moeller types.
Frequency converter
EN50178
compliant fuses
UL Compliant fuses Recommended circuit breaker
Bussmann SIBA Little fuse IP20 IP55
Size Type Type RK1 Type J Type T Type RK1 Type RK1 Type RK1 Moeller type
200-240 V
CDS-15kW 125 A gG KTN-R125 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R NZMB1-A100 NZMB2-A200
CDS-18.5 kW 125 A gG KTN-R125 JKS-150 JJN-125 2028220-125 KLN-R125 A2K-125R NZMB2-A200 NZMB2-A200
CDS-22 kW 160 A gG FWX-150 - - 2028220-150 L25S-150 A25X-150 NZMB2-A200 NZMB2-A200
380-480 V
CDS-15 kW 63 A gG KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R50 A6K-50R PKZM4-50 PKZM4-63
CDS-18.5 Kw 63 A gG KTS-R60 JKS-60 JJS-60 5014006 -063 KLS-R60 A6K-60R NZMB1-A100 NZMB1-A100
CDS-22 kW 80 A gG KTS-R80 JKS-80 JJS-80 2028220-100 KLS-R80 A6K-80R NZMB1-A100 NZMB1-A100
525-
600V
CDS-18.5 kW 40A gG KTS-R50 JKS-50 JJS-50 5014006-050 KLS-R50 A6K-50R NZMB1-A100 -
CDS-30 kW 63A gG KTS-R80 JKS-80 IJS-80 5014006-080 KLS-R80 A6K-80R NZMB1-A100 -
