Danfoss VZH Series Application Guidelines

Application guidelines
67FRCC.PC.023.A7.22
Single compressorsOrdering information and packaging
The tables on the following pages give code
numbers for ordering purposes for the VZH
compressor and CDS303 frequency converter kit
packed and shipped separately.
VZH scroll compressors can be ordered in single
packs or industrial packs while VZH frequency
converters can only be ordered in single pack.
Please use the code numbers from below tables
for ordering. A coil for injection valve must be
ordered separately.
Kit ordering and shipping
Compressor single pack
Packaging
Frequency converter single pack
Compressors single pack
Ordering information
Compressor model
Height
(in)
Width
(in)
Depth
(in)
Weight
(lb)
VZH088 28.3 22.2 18.5 154.3
VZH117 28.3 22.2 18.5 167.6
VZH170 30.1 20.3 17.7 247.0
Drive
supply
voltage
Drive
power
(kW)
IP20 IP55
Height
(in)
Width
(in)
Depth
(in)
Weight
(lbs)
Height
(in)
Width
(in)
Depth
(in)
Weight
(lbs)
T2:
Code J
15 13.6 31.9 12.6 53.0 16.9 31.7 15.9 101.0
18 - 22 17.2 31.7 12.9 79.0 17.2 31.7 15.9 101.0
T4:
Code G
15 13.7 19.7 13.0 28.7 13.6 31.9 12.6 53.0
18 - 22 13.6 31.9 12.6 53.0 13.6 31.9 12.6 62.0
T6:
Code G
18.5-30 13.6 31.9 12.6 53.0 - - - -
Depth
Height
Width
CD303 packaging
Compressor industrial pack
Compressor model Nbr*
Length
(in)
Width
(in)
Height
(in)
Gross Weight
(kg)
Static stacking
pallets
VZH088 8 45.3 37.4 26.8 1089 2
VZH117 8 45.3 37.4 29.5 1199 2
VZH170 4 1150 40.0 30.2 1426 2
Compressor model Pressure ratio Equipment version Technical Name
X=motor code
G
380-480V/3ph/
50&60Hz
J
200-240V/3ph/
50&60Hz
H
525-600V/3ph/
50&60Hz
VZH088
High Single VZH088AXANA 120G0010 120G0012 120G0047
Low Single VZH088BXANA 120G0011 120G0013 120G0049
High Manifold VZH088AXBNA 120G0022 120G0024 120G0048
Low Manifold VZH088BXBNA 120G0023 120G0025 120G0050
VZH117
High Single VZH117AXANA 120G0014 120G0016 120G0051
Low Single VZH117BXANA 120G0015 120G0017 120G0053
High Manifold VZH117AXBNA 120G0026 120G0028 120G0052
Low Manifold VZH117BXBNA 120G0027 120G0029 120G0054
VZH170
High Single VZH170AXANB 120G0018 120G0020 120G0055
Low Single VZH170BXANB 120G0019 120G0021 120G0057
High Manifold VZH170AXBNB 120G0030 120G0032 120G0056
Low Manifold VZH170BXBNB 120G0031 120G0033 120G0058
