Danfoss VZH Series Application Guidelines

Application guidelines
72 FRCC.PC.023.A7.22
Single compressorsAccessories
Type Code n° Description Application Packaging Pack size
120Z0066
Mounting kit for 1 scroll compressor including 4 grommets, 4
sleeves, 4 bolts, 4 washers
VZH088-117 Single pack 1
8156138
Mounting kit for 1 scroll compressor including 4 grommets, 4
sleeves, 4 bolts, 4 washers
VZH170 Single pack 1
Mounting kits
Type Code n° Description Application Packaging Pack size
120Z0521 Coil / 208-240V and adaptor VZH all models Single pack 1
120Z0522 Coil / 24V and adaptor VZH all models Single pack 1
Terminal boxes, covers & T-block connectors
Coil
Type Code n° Description Application Packaging Pack size
8173230 T block connector 2.05x2.24 inch (52 x 57 mm) VZH088-G/H, VZH117-G/H Multipack 10
8173021 T block connector 2.36x2.56 inch (60 x 75 mm) VZH088-J.VZH117-J.VZH170-G/H Multipack 10
8173331 T block connector 3.15x3.15 inch (80 x 80 mm) VZH170-J Multipack 10
120Z0146 Electrical box VZH088-G/H.VZH117-G/H Single pack 1
120Z0147 Electrical box VZH170-J Single pack 1
120Z0148 Electrical box VZH088-117-J Single pack 1
120Z0538 Electrical box VZH170-G/H Single pack 1
120Z0149 Electrical box cover VZH088-G/H.VZH117-G/H Single pack 1
120Z0150 Electrical box cover VZH170-J Single pack 1
120Z0537 Electrical box cover VZH170-G/H Single pack 1
120Z0151 Electrical box cover VZH088-117-J Single pack 1
Valve Body
Type Code n° Description Application Packaging Pack size
120Z0145 Valve body VZH all models Single pack 1
Type Code n° Description Application Packaging Pack size
160SZ 7754023 POE lubricant, 160SZ, 1.05 quart can VZH with R410A Multipack 12
Lubricant / oils
Oil level switch
Spare parts frequency converter
LCP ’s
Type Code n° Description Application Packaging Pack size
120Z0560 Oil level switch screw in- mechanical part all models Single pack 1
120Z0561 Oil level switch - electrical part (24V AC/DC) all models Single pack 1
120Z0562 Oil level switch - electrical part (230V AC) all models Single pack 1
Type Code n° Description Application Packaging Pack size
120Z0326 LCP display Frequency converter / all models Single pack 1
175Z0929 RS cable to LCP Frequency converter / all models Single pack 1
130B0264 LCP cradle, required to mount the LCP on IP55 casings Frequency converter / all models Single pack 1
