Inserting the ribbon cassette User guide
20
Slightly tilt the ribbon cassette forwards and thread
in the ribbon between the coloured insertion
tongue and the ribbon support (transparent plastic
plate).
Align and insert the cassette into the guides on the
left and right, then press down until it clicks into
place.
Insert the coloured tension knob into one of the
two locations.
Turn the tension knob in the direction of the arrow
to take up slack in the ribbon until it is seated cor-
rectly at the bottom in the ribbon support.
Remove the knob.
STOP
