User guide The Menu
73
Ethernet interface
(ETH-INT)
In this parameter group you can choose settings for the internal
Ethernet interface.
Press ETH-INT (2) key.
If an optional Ethernet print server (modular or pocket) is
installed, ETH-EXT can be set via key 3.
Setting IP address (IP Addr) Input of the IP address of the printer.
Press IP Addr (2) key.
This menu level offers the possibility to set the IP address, which is
divided into four digit groups (octet 1 to 4). You can activate octet 3
and 4 by pressing the Next (2) key.
Press OCTET 1 (2) key.
Use the < (2) or > (3) key to select the desired digit.
Setting Options: 0 to 255
Default Setting: 0
Confirm the setting by pressing the Set key (1).
Set the remaining three digit groups in the same way.
ETH-INT
Online
Setup
Back Next
21
3
4
IP Addr Gateway
Online
Setup
Back Next
21
3
4
OCTET 1 OCTET 2
Online
Setup
Back Next
21
3
4
OCTET 1= 0 *
Online
Setup
Set < > Exit
21
3
4
