DataCard CD800 Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide 93
The following laminator supplies are available. Most are available for a full card, smart card, or
magnetic stripe card. Contact your dealer for a complete list of laminator supplies.
Patch:
 Clear DuraGard®, 0.5 mil, up to 350 images/roll
 Clear DuraGard, 1.0 mil, up to 300 images/roll
 Holographic DuraGard 0.6 mil, Random, up to 350 images/roll
 Holographic DuraGard, Registered, 0.6 mil, up to 350 images/roll
 Holographic DuraGard, 1.0 mil, Random, up to 300 images/roll
 Holographic DuraGard Registered, 1.0 mil, up to 300 images/roll
Topcoat:
 Clear, number of images depends on lamination settings
 Holographic, Random, number of images depends on lamination settings
 Registered Holographic, up to 600 images/roll
 Clear DuraShield™, number of images depends on lamination settings (see note)
 Holographic DuraShield, Random, number of images depends on lamination settings (see
note)
 Holographic DuraShield, Registered, 500 images/roll (see note)
Caution: DuraGard patch overlay cannot be applied over a “T” panel topcoat applied
from a ribbon. Make sure that the DuraGard patch is applied to the card side without
a “T” panel topcoat.
DuraShield clear and holographic overlays must be used with a ribbon that includes
an inline topcoat (T) panel, for example, KT, YMCKT, YMCKT-K, YMCKT-KT, ymcKT, or
YMCKF-KT. It must be applied over the topcoat.

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
