DataCard CD800 Installation And Administrator's Guide

A-10 SD460 Laminating System
Load Laminator Overlay Material
Load the overlay material in one laminator cartridge at a time.
1. Open the laminator door.
2. Remove the L1 (green) laminator cartridge
from the laminator. Place the cartridge on a
smooth, level surface for loading.
3. Push the release latch (a) and open the gate
on the laminator cartridge (b).
The L1 (green) and L2 (orange) cartridges fit only in their assigned locations inside
the laminator. They are not interchangeable.

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
