DataCard CD800 Installation And Administrator's Guide

8 Installation
Install the Ribbon Cartridge
Install the assembled print ribbon cartridge into the printer.
1. Open the printer cover.
2. Hold the print ribbon cartridge by the handle and
lower it into the printer with the handle toward the
front of the printer.
3. Make sure that the ribbon cartridge is correctly
positioned in the guides.
4. Close the printer cover. Press down on the ridges on
the front of the cover to make sure that it latches
completely on both sides.

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
