DataCard CD800 Installation And Administrator's Guide

A-2 SD460 Laminating System
SD460 Site Requirements
Provide space for the system and for clearance around the system. Refer to “Site Requirements”
on page3 for information about selecting a location for the system.
System Dimensions
The external system dimensions are shown in the following illustration.
20.2 in
513 mm
10.6 in
270 mm
23.8 in / 604 mm
27.1 in / 689 mm
(with impresser)

DataCard CD800 Specifications

General

Print Resolution	300 dpi
Weight	12 lbs (5.4 kg)
Power Requirements	100-240 VAC, 50/60 Hz
Print Technology	Dye-sublimation
Card Capacity	100 cards (standard hopper)
Connectivity	USB
Card Size	CR80 (85.6 mm x 54 mm)
Operating System Compatibility	Windows
Card Thickness	0.020" - 0.040" (0.51 mm - 1.02 mm)
