22 Installation
Load Test Cards in the Hopper
The system comes with a set of test cards in the shipping box. Load these blank cards initially to
produce test cards and verify system operation.
Single-Hopper System
1. Unlock the printer and open the input hopper.
2. Load the test cards into the input hopper.
Insert ISO magnetic stripe cards with the stripe (back side)
facing down and to the right. A diagram inside the input
hopper shows the correct orientation.
3. Close the hopper door and lock the printer.
Multi-Hopper Printer
1. Unlock the printer and open the multi-
hopper.
2. Load the cards into hopper H1.
Insert ISO magnetic stripe cards with the
stripe (back side) facing down and to the
right. A diagram inside the input hopper
shows the correct orientation.
3. Close the multi-hopper door and lock the
printer.
