CE870 Instant Issuance System Installation and Administrator’s Guide 33
b. Select the test card options. Refer to “Test Card” on page98 for a complete description of
the Printer Manager test card options.
i. Select hopper 1 from the Input Hopper Number drop-down menu.
ii. Select the Emboss check box and one of the following:
– TestCard1 to test emboss character position.
– TestCard3 to test the indent printing and topping quality.
– TestCard5 and TestCard6 to test the emboss character height.
iii. Select the Magnetic Stripe check box.
iv. Clear the Color check box from the front and back options if color printing is not
available on the system.
If color printing is available with the system, select the Color check box
while running TestCard1.
