Datacard CR500 User Reference Guide Clean the System
29
28
7. Move the cleaning card through the printer.
a. Rotate the shule to the down posion.
b. Push the excepon card slide in, past the resistance unl it reaches the
stop posion.
c. Push the card to the print unit card feed roller.
d. Stop when the card is under the roller and engages the printer.
7a
7b
7c
7d
8
8. Power on the printer. The message “Film Search A1” displays on the print unit
front panel.
9. Use the print unit front panel to run the cleaning card.
a. Press Menu to display “Cleaning”.
b. Press Enter to display “Rollers OK?”.
c. Press Return to display “Film checking” followed by “Cleaning Start OK”.
d. Press Return.
The print unit pulls the cleaning card into the print unit and cleaning begins.
If the card is not pulled into the unit and no errors display, lightly push
the card unl the roller catches it and the card moves into the unit.
10. The cleaning card is discharged and “Cleaning Start OK?” displays again.
11. Turn the cleaning card over and place it in the excepon card slide with the
scky side facing down. Refer to step 7 to posion the card properly.
12. Press Return.
13. When the cleaning card is discharged, press Exit to end the cleaning process.
14. Discard the used cleaning card.
Cauon: Use a cleaning card one me only. Reusing a card can damage
the rollers.
15. When cleaning is complete:
a. Reinstall the retransfer lm cartridge.
b. Replace the concealed output stacker.
Refer to “Prepare the Printer for Use” on page 34.
