DataCard SD460 User Manual

48 Card Printer Driver Management Tasks
Port Type
The Port Type displays the connection type and the printer IP address:
 USB—The printer is connected locally via USB.
 Network—The printer is connected using a network connection. The network IP address can
be either IPv4 or IPv6.
Printer Information
The Printer Information box shows the following:
Print a Driver Sample Card
You can print sample cards from the Printer Status tab to verify that the Card Printer Driver and
the printer are communicating.
The Printer sample card shows a basic ID card that can be printed with any ribbon that the printer
supports. The test card images and text do not change.
The magnetic stripe test card is available when the printer includes a magnetic stripe option. The
magnetic stripe test card verifies that the Card Printer Driver sends magnetic stripe data to the
printer and that the printer encodes it. The test data cannot be changed.
The Card Printer Driver includes the following sample cards:
 Printer Sample Card
Model Model name of the printer
Serial Number Printer serial number assigned at the factory
Firmware Version Version of the firmware currently installed in the printer
Protocol DPCL protocol used by the driver to communicate with the printer
Option Information Options or features included in this printer

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
