XPS Card Printer Driver User’s Guide 81
Print Area Tab
The Print Area tab allows you to specify printing and non-printing areas on the card.
 For card printers that support printing to rewritable cards, you use the Print Area tab to
specify erase options (refer to “Select an Erase Pattern” on page 86). Refer to “Printer Setup
for Rewritable Cards” on page 96 for a complete discussion of how to set up your system to
use the rewritable feature.
 The CR805 retransfer printer uses the Print Area tab to block printing over the smart card
chip on the front of the card and specify the area to which to apply the inhibitor panel of the
ink ribbon on the back of the card. Refer to “Retransfer Printer Print Area Tab” on page 88.
Print and Topcoat Blocking
The Card Printer Driver can prevent printing and topcoat application on specific areas of the card.
This includes the magnetic stripe, smart card chip, signature panel, or another area that must
remain unprinted or without topcoat.
The Print Area tab provides a selection of standard blocking patterns that use a driver preset
mask, which automatically applies the proper dimensions and locations of a smart card chip and
magnetic stripes for print blocking. For more information about non-printing areas of a card, refer
to the printer’s Installation and Administrator’s Guide.
To return the Print Area tab to the default settings, click Restore Defaults. The default print and
topcoat settings are:
 Front Side Print Area: Print and topcoat entire side of card
 Back Side Print Area: Print and topcoat entire side of card
 Custom bitmap is not selected
 If the predefined blocking selections offered by the Card Printer Driver do not fit the
card design, you can use escapes to define custom rectangular areas for printing and
topcoat application, including defining more than one blocking area per side of a card.
Refer to “Print Blocking Escapes” on page 103.
 You also can create a custom topcoat blocking pattern that is not available with the
topcoat settings offered by the Card Printer Driver or through escapes. The custom
pattern can be a non-rectangular shape or another shape based on a graphic image
bitmap, such as a logo. Refer to “Use a User-Defined Topcoat Bitmap” on page 83.
If you are using YMCK or YMCK-K ribbon (ribbons without a topcoat panel), the topcoat
blocking preferences are ignored. Print blocking preferences function normally.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
