DataCard SD460 User Manual

XPS Card Printer Driver User’s Guide 67
2. Start your application and select the card printer as the
current printer.
3. Use the application’s page setup options to set the correct
paper size for your printer.
4. Set the margins to 0.
5. Format the text and graphics to print on the card.
Refer to the printer’s Installation and Administrator’s
Guide for more information about card design.
Printer Paper Size Dimensions
SD/CD/CE series
printers
ISO ID-1 2.13 x 3.38 in.
CR805 Retransfer
Card Printer
ISO ID-1
Retransfer
2.23 x 3.51 in.
Your PC application’s Print settings may override
the settings specified in the Card Printer Driver.
Make sure that your application’s Print settings
specify “Print on both sides.”

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
