DataCard SR200 User Manual

60 Printer and Laminator Settings
HR‐TTemp
90degCto180degC
Displaysthesetpointtemperatureofthetopheat
roller.(Thetemperaturemaybe185°Corhigher
dependingonthefirmwareversionofthecardprinter.)
HR‐BTemp
90degCto180degC
Displaysthesetpointtemperatureofthebottomheat
roller.(Thetemperaturemaybe185°Corhigher
dependingonthefirmwareversionofthecardprinter.)
Speed
3.0mm/sto12.0mm/s
Displaysthecardspeedduringlamination.
CoolingTime
0sec,5sec,7sec,10sec,
15sec,20sec,30sec
Displaysthestandbytimeforcoolingdownthecard
beforelaminationstarts.
HRControl
 Off
 On
Displayswhetherthelaminatorenterslow
temperaturestandbymodewhennotinuse.HR
controlissetonthePrinterSettingtaboftheStatus
Monitor.
ThisisalwayssettoOnautomaticallywhenoverlay
filmisselectedontheLaminatortab.
(Regardlessofthesetting,putthelaminatorinto
standby
modeifyouwill notbeprintingcardsfora
longtime.)
Count Displaysthenumberoflaminationsperformedafter
thelastrollercleaning.Thisnumberisresetto0each
timearollercleaningisperformed.
Network
PrinterName
 PRINTER01to
PRINTER09
DisplaystheNetworkNameoftheprinter.Usethe
StatusMonitortochangethisnamewhenmorethan
oneSR200orSR300printerisconnectedtothe
network.Selectfromthenamessupplied.
IfyousetupanetworkprinteronthePCusingaUSB
connection,thisnamecanbe
assignedfromthePC.
HostIF
 USB
 LAN
DisplaystheconnectionmethodfortheprinterandPC,
eitherUSBorLAN(Ethernet).Thesettingdefaultsto
USBwhentheprinterisconnectedtoaPCusingaUSB
cable.
MenuDisplay Settings Function
