DM984 product family CHAPTER 14. SUPPORTED MES
14.2.61 Traffic Scheduler
An instance of this managed entity represents a logical object that can control
upstream GEM packets. A traffic scheduler can accommodate GEM packets
after a Priority Queue or another Traffic Scheduler Manage Entity and transfers
them towards the next Traffic Scheduler or to a T-CONT.
Supported Attributes
Attribute DM984-
100B
IPSAN
T-CONT Pointer yes yes
Traffic Scheduler Pointer yes yes
Policy yes yes
Priority or Weight yes yes
14.2.62 UNI-G
This managed entity organizes data associated with user network interfaces
(UNIs) supported by GEM. One instance of the UNI-G managed entity exists
for each UNI supported by the ONU.
Supported Attributes
Attribute DM984-
100B
IPSAN
Configuration Option Status - -
Administrative state yes -
Management capability yes -
Non-OMCI management identifier yes -
14.2.63 Virtual Ethernet interface point
This managed entity represents the data plane hand-off point in an ONU to
a separate (non-OMCI) management domain. The virtual Ethernet interface
point is managed by the OMCI, and is potentially known to the non-OMCI
management domain. One or more Ethernet traffic flows are present at this
boundary. Instances of this managed entity are automatically created and deleted
by the ONU. This is necessary because the required downstream priority queues
