DM984 product family CHAPTER 11. IPSAN CONFIGURATION
default-gw <gateway-ip>
Description of the used parameters:
Name Format Description
<gateway-ip> IPv4 address Default gateway of the ONU
Example:
DM4650(config-if-gpon-7/3/2)#default-gw 10.0.0.1
DM4650(config-if-gpon-7/3/2)#
11.9 Configuring the Uplink Interface
The uplink interface is used to connect the GPON to the service providers in-
ternal network. It depends on the built-in cards how many Ethernet ports are
potentially available to act as uplink. The IPSAN itself features 2 Ethernet ports
that may be used as uplink. For other configurations that are possible for uplink
operation please refer to the IPSAN’s manual.
The following steps are done in the configuration menu. First it is necessary
to switch to the configuration menu of an Ethernet interface via
interface ethernet <id>
Description of the used parameters:
Name Format Description
<id> Number (1-2) Interface ID of the Ethernet port
In the submenu the following configurations need to be done.
mode confluent
no negotiation
Note: For a brief description on the used commands please refer to the IPSAN’s
manual.[1]
Finally, the port is brought up via:
no shutdown
Example configuration of an uplink port:
DM4650(config)#interface ethernet 1
DM4650(config-if-eth-1/1)#mode confluent
DATACOM
204.4288.00
