DM984 product family CHAPTER 14. SUPPORTED MES
Attribute DM984-
100B
IPSAN
Operational State yes -
14.2.21 GEM Port Network CTP
This managed entity represents the termination of a GEM port on an ONU. This
managed entity aggregates connectivity functionality from the network view and
alarms from the network element view as well as artefacts from trails.
Supported Attributes
Attribute DM984-
100B
IPSAN
Port ID Value yes yes
T-CONT Pointer yes yes
Direction yes yes
Encryption State yes yes
Traffic Management Pointer for Upstream yes yes
Traffic Descriptor Profile Pointer for Upstream yes yes
UNI Counter yes yes
Priority Queue Pointer for Downstream yes yes
Traffic Descriptor Profile Pointer for Down-
stream
yes yes
14.2.22 GEM Port Network CTP Performance Monitoring
History Data
This managed entity collects GEM frame performance monitoring data associated
with a GEM port network CTP.
Supported Attributes
Attribute DM984-
100B
IPSAN
Interval End Time - yes
Threshold Data 1/2 id - yes
Port ID Value yes -
DATACOM
204.4288.00
