DM984 product family CHAPTER 14. SUPPORTED MES

Attribute DM984-

100B

IPSAN

Fragments - yes

Jabbers yes yes

Packets 64 octets yes yes

Packets 65 to 127 octets yes yes

Packets 128 to 255 octets yes yes

Packets 256 to 511 octets yes yes

Packets 512 to 1023 octets yes yes

Packets 1024 to 1518 octets yes yes

14.2.16 Extended VLAN Tagging Operation Conﬁguration

Data

This managed entity deﬁnes the VLAN handling of incoming and outgoing

frames, it can be positioned on the UNI side of a bridge/802.1p mapper, on

the ANI side, or on both sides and deﬁnes the upstream actions. If the down-

stream operation is enabled, it shall be the inverse of the upstream operation.

Otherwise the downstream data is not modiﬁed.

Supported Attributes

Attribute DM984-

100B

IPSAN

Association Type yes yes

Association ME Pointer yes yes

Received Frame VLAN Tagging Operation Table

Max Size

yes -

Downstream Mode yes yes

DSCP to P-bit Mapping yes -

Default Rules yes -

Forwarding ID Assignment yes -

Input TPID - Upstream yes yes

Output TPID - Upstream yes yes

Filter Outer Priority yes yes

Filter Inner Priority yes yes

Filter Outer VID - Upstream yes yes

Filter Outer TPID/DE - Upstream yes yes

Filter Inner VID - Upstream yes yes

DATACOM

204.4288.00
