DM984 product family CHAPTER 14. SUPPORTED MES

are subject to physical implementation constraints. The OLT may use one or

more of the virtual Ethernet interface points created by the ONU.

Supported Attributes

Attribute DM984-

100B

IPSAN

Administrative State - -

Operational State - -

Interdomain name - -

TCP/UDP pointer yes -

IANA assigned port yes -

14.2.64 VLAN Tagging Filter Data

This managed entity deﬁnes VLAN IDs that shall be handled by the hardware.

The given attributes are commonly used in upstream and downstream direction

but must be conﬁgured to the ingress and egress hardware separately.

Supported Attributes

Attribute DM984-

100B

IPSAN

VLAN Filter List yes yes

Forward Operation yes yes

Number of Entries yes yes

14.2.65 VLAN Tagging Operation Conﬁguration Data

This managed entity deﬁnes the VLAN handling of incoming and outgoing

frames, it can be positioned either on the UNI side of a bridge or on the ANI

side and controls upstream as well as downstream actions.

In contrast to the Extended VLAN Tagging Operation Conﬁguration Data man-

aged entity this one provides less functionality in terms of VLAN manipulation

and is used in older GPON systems. These two VLAN-related managed entities

are used either/or, but not concurrently in the same system application.
