Datacom DM984-100B - Configuring the VLAN Interface

DM984 product family CHAPTER 11. IPSAN CONFIGURATION
DM4650(config-if-eth-1/1)#no negotiation
DM4650(config-if-eth-1/1)#no shutdown
DM4650(config-if-eth-1/1)#exit
DM4650(config)#
11.10 Configuring the VLAN Interface
When a VLAN is configured to be used in the FLOW-Profile a VLAN interface
needs to be created. For this purpose the following command must be issued:
interface vlan <vid>
Description of the used parameters:
Name Format Description
<vid> Number (1-4094) VLAN ID of the VLAN interface
As a next step it is necessary to add all ONUs and uplink interfaces to the
same VLAN. This enables interconnection between the Ethernet ports and pon-
links. Each configured uplink interface, as well as ONU needs its own rule.
Below are examples of rules defined for an ONU and an Ethernet interface as
uplink.
set-member gpon <unit>/<ponlink> onu <id> virtual-port 1
set-member ethernet <if> <tagged|untagged>
Description of the used parameters:
Name Format Description
<unit> Number (1-7) Card slot of the plugged in GPON card
<ponlink> Number (1-8) Ponlink the ONU is connected to
<if> Number (1-2) Gigabit Ethernet interface number
Example configuration of a VLAN interface:
DM4650(config)#interface vlan 333
DM4650(config-if-vlan-333)#set-member gpon 7/1 onu 1 virtual-
,→ port 1
DM4650(config-if-vlan-333)#set-member ethernet 1 tagged
DM4650(config-if-vlan-333)#exit
DM4650(config)#
