DM984 product family CHAPTER 13. EXAMPLES
no negotiation
no shutdown
exit
interface vlan 120
set-member gpon 7/1 onu 1 virtual-port 1
set-member ethernet 1 tagged
exit
interface vlan 121
set-member gpon 7/1 onu 1 virtual-port 2
set-member ethernet 2 tagged
exit
13.3 VLAN Translation Setup
configure
profile gpon flow single_user
add-rule 1 uni-type eth uni-port all vlan 500 virtual-port 1
add-rule 2 uni-type eth uni-port all vlan 600 virtual-port 1
exit
vlan-translate-gpon
add single one-vlan-rule mod-vlan user-vlan any user-prio any
,→ vlan 500 sprio cpy-user-prio
add double two-vlan-rule mod-vlan user-cvlan any user-cprio any
,→ user-vlan 300 user-sprio any vlan 600 sprio 7
exit
unit-gpon 7
authentication-method serial-number
exit
interface gpon 7/1
no shutdown
onu 1 serial-number DACM00000000
flow-profile single_user
eth-uni 1
native-vlan vlan 500
vlan-translation-rule single
vlan-translation-rule double
exit
virtual-port 1
allowed-ip all
exit
exit
exit
interface ethernet 1
mode confluent
no negotiation
no shutdown
