DM984 product family CHAPTER 11. IPSAN CONFIGURATION
Note: When the chosen id is already taken it will change the existing entry.
For an assignment to a specific Ethernet interface the following command is
given:
add-rule <id> uni-type eth uni-port <eth-uni> vlan <vid> virtual
,→ -port <vp-id>
Description of the used parameters:
Name Format Description
<id> Number (1-32) ID of the FLOW rule
<vid> Number (1-4094) VLAN ID to be used
<vp-id> Number (1-16) ID of one of the previously defined virtual ports
<eth-uni> Number Ethernet port number
Note: When the chosen id is already taken it will change the existing entry.
A special rule exists if the user wants to add not only a VLAN ID but also a
VLAN priority to the ONU connection:
add-rule <id> uni-type eth uni-port all vlan+pbit <vid> pbit <
,→ pbit> virtual-port <vp-id>
Description of the used parameters:
Name Format Description
<id> Number (1-32) ID of the FLOW rule
<vid> Number (1-4094) VLAN ID to be used
<pbit> Number (0-7) VLAN Priority bit
<vp-id> Number (1-16) ID of one of the previously defined virtual ports
Note: When the chosen id is already taken it will change the existing entry.
The VLAN id also up to the user.
Example for FLOW-Profile creation:
DM4650(config)#profile gpon flow 123
DM4650(config-prof-gpon-flow-123)#add-rule 1 uni-type eth uni-
,→ port all vlan 100 virtual-port 1
DM4650(config-prof-gpon-flow-123)#exit
DM4650(config)#
DATACOM
204.4288.00
