DK-40 USER MANUAL V2.6 (02.08.2011)
K13D01-E - 36 -
CONTROLLER REGISTERS
ADDR. NAME DESCRIPTION LENG. R/W TYPE MUL.
40033
Motor Status
Current motor status
0: Compressor in OFF mode
1: Motor star
2: Motor delta (before load)
3: Motor loaded
4: Motor unloaded
5: Motor stopped,
compressor in RUN mode
16 BIT R-O unsigned word 1
40034 Fault Code
Current alarm or warning or
service code
16 BIT R-O unsigned word 1
40035 Relay status
Current relay status bits
bit 1-3:-
bit 4: Line relay
bit 5: RL5 (alarm/fan)
bit 6: Load relay
bit 7: Delta relay
bit 8: Star relay
bit 9-16: -
16 BIT R-O unsigned word 1
40036 - - 16 BIT R-O unsigned word 1
40037 Alarm 1 Alarm 1 in alarm history 16 BIT R-O unsigned word 1
40038 Alarm 2 Alarm 2 in alarm history 16 BIT R-O unsigned word 1
40039 Alarm 3 Alarm 3 in alarm history 16 BIT R-O unsigned word 1
40040 Alarm 4 Alarm 4 in alarm history 16 BIT R-O unsigned word 1
40041 Alarm 5 Alarm 5 in alarm history 16 BIT R-O unsigned word 1
40042 Alarm 6 Alarm 6 in alarm history 16 BIT R-O unsigned word 1
40043 Alarm 7 Alarm 7 in alarm history 16 BIT R-O unsigned word 1
40044 Alarm 8 Alarm 8 in alarm history 16 BIT R-O unsigned word 1
40045 Alarm 9 Alarm 9 in alarm history 16 BIT R-O unsigned word 1
40046 Connection topology
1:Single phase, 2:bi-phase
3: three phase
16 BIT R-O unsigned word 1
40047
-
40128
reserved - 16 BIT R-O unsigned word 1
PROGRAM PARAMETERS
ADDR. NAME DESCRIPTION LENG. R/W TYPE MUL.
40129 P01 See chapter 9.2 16 BIT R/W unsigned word 1
40130 P02 See chapter 9.2 16 BIT R/W unsigned word 0.1
40131 P03 See chapter 9.2 16 BIT R/W unsigned word 0.1
40132 P04 See chapter 9.2 16 BIT R/W unsigned word 0.1
40133 P05 See chapter 9.2 16 BIT R/W unsigned word 0.1
40134 P06 See chapter 9.2 16 BIT R/W signed word 0.1
40135 P07 See chapter 9.2 16 BIT R/W signed word 1
40136 P08 See chapter 9.2 16 BIT R/W signed word 1
40137 P09 See chapter 9.2 16 BIT R/W signed word 1
40138 P10 See chapter 9.2 16 BIT R/W signed word 1
