10.2. MODBUS REGISTER LIST
CONTROLLER REGISTERS
ADDR. NAME DESCRIPTION LENG. R/W TYPE MUL.
40001 Frequency 16 BIT R-O unsigned word 0.1
40002 Phase L1 Voltage 16 BIT R-O unsigned word 1
40003 Phase L2 Voltage 16 BIT R-O unsigned word 1
40004 Phase L3 Voltage 16 BIT R-O unsigned word 1
40005 Phase L1-L2 Voltage 16 BIT R-O unsigned word 1
40006 Phase L2-L3 Voltage 16 BIT R-O unsigned word 1
40007 Phase L3-L1 Voltage 16 BIT R-O unsigned word 1
40008 Pressure Pressure Value 16 BIT R-O unsigned word 0.1
40009 Air end temperature Temperature Value 16 BIT R-O signed word 1
40010 Motor PTC ohm read in ohms 16 BIT R-O signed word 1
40011 Temperature 2 Measured from Sensor 2 16 BIT R-O signed word 1
40012 Pressure 2 Measured from Sensor 2 16 BIT R-O unsigned word 0.1
40013
Service A Counter remaining time to service A 32 BIT R-O signed long 0.1
40014
40015
Service B Counter remaining time to service B 32 BIT R-O signed long 0.1
40016
40017
Service C Counter remaining time to service C 32 BIT R-O signed long 0.1
40018
40019
Service D Counter remaining time to service D 32 BIT R-O signed long 0.1
40020
40021
Service E Counter remaining time to service E 32 BIT R-O signed long 0.1
40022
40023
Total Working Hour
Total controller time
(LOAD + UNLOAD + STOP)
32 BIT R-O unsigned long 0.1
40024
40025
Total Engine Hour
Total Engine working
hour(LOAD+UNLOAD)
32 BIT R-O unsigned long 0.1
40026
40027
Total Load Hour
Total Engine loaded
hour(LOAD)
32 BIT R-O unsigned long 0.1
40028
40029
Alarms
alarm bits (see alarm list at
chapter 10.3)
32 BIT R-O unsigned long 1
40030
40031 Warnings
warnings bits (see alarm list
at chapter 10.3)
16 BIT R-O unsigned word 1
40032 Service requests
maintenance register (see
list at chapter 10.3)
16 BIT R-O unsigned word 1
