Datakom DK-40 User Manual

DK-40 USER MANUAL V2.6 (02.08.2011)
K13D01-E - 24 -
9.2. PARAMETER LIST
Some parameters given in this list may not appear on
device display.
No Description Adjustment Range Factory set
P01 Pressure Control
0: Analog transducer
1: Pressure Switch
If this parameter is set to 1 then
P02 ... P06 parameters are not
displayed.
0
P02
Top Range of Pressure
Transducer
4.2 ... 99.9 15.0 bar
P03 High Pressure Alarm (P02-0.5) ... (P04+0.5) 8.5 bar
P04 Stop Pressure (P03-0.2) ... (P05+0.2) 7.3 bar
P05 Start Pressure 3 ... (P04-0.2) 6.5 bar
P06 Offset Pressure Transducer -2 ... +2 0 bar
P07
Top range temperature
probe
(P08+2) ... 130 130 °C
P08
High air end temperature
Alarm
(P09+2) ... (P07-2) 108 °C
P09
High air end temperature
Warning
(P10+2) ... (P08-2) 103 °C
P10
Low air end temperature
Alarm
-10 ... (P09-2) 0 °C
P11
Offset value air end
temperature
-10 ... +10 0 °C
P12 Motor PTC Enable
0:Disable
1: Enable
If this parameter is set to 1, then
when the resistance measured at
the Motor PTC input is above
2000 ohms this will generate an
A09 Motor PTC high
temperature alarm.
0

Datakom DK-40 Specifications

Power

supply voltage (IN-COMM to IN-400V)	305 – 460 VAC
supply voltage (IN-COMM to IN-230V)	175 - 275 VAC
supply frequency	50 - 60 Hz nominal
power consumption	< 4 VA

Measurement Inputs

voltage input range (L-L)	20 - 520 V AC
voltage input range (L-N)	10 - 300 V AC
frequency input range	30 - 100 Hz

Accuracy

voltage accuracy	0.5% + 1 digit
frequency accuracy	0.5% + 1 digit
voltage burden	< 0.1 VA per phase

Relay Outputs

relay output current	5 A
relay output voltage	250 V AC
external switch resistance	< 3 K-ohms

Inputs

pressure input range	4-20 mA (optional 0-10 V)
temperature input range	1000-5000 ohms
motor PTC input alarm threshold	2000 ohms

Operating Environment

operating temperature	-30°C to +80°C (-22°F to +176°F)
storage temperature	-40°C to +80°C (-40°F to +176°F)
maximum humidity	95% non-condensing

Physical Characteristics

degree of protection (front panel)	IP 54
degree of protection (back panel)	IP 30
dimensions	134x107x54 mm (WxHxD)
