Datakom DK-40 User Manual

DK-40 USER MANUAL V2.6 (02.08.2011)
K13D01-E - 16 -
6.2. MODIFYING HOUR COUNTERS
The unit holds 3 different run hour counters:
MESSAGE DESCRIPTION
C-H
C-HC-H
C-H
Total compressor hours (ON_LOAD+OFF_LOAD+STOP)
This counter increments while the RUN led is on.
R-H
R-HR-H
R-H
Total motor run hours
(ON_LOAD+OFF_LOAD)
This counter increments while the motor runs.
L-H
L-HL-H
L-H
Total load time (load contactor active)
This counter increments while LOAD led is on.
Hour counters can only be modified while the compresor
is in STOP mode.
In order to modify hour counters:
- Hold pressed together MENU , RUN and STOP buttons for 3 seconds. If
the high level password is not entered in the last 90 minutes, the unit will ask password
(US R
USRUSR
USR).
- Enter password.
- The upper display will show C-H
C-HC-H
C-H message.
- Adjust required hour counter value with RUN and STOP buttons.
- Press MENU button for 3 seconds, the display wil show SEt message and the
counter will be adjusted to the new value. If MENU button is pressed for short
duration, then the value will not be modified and the next hour counter will be displayed.
Same steps are repeated for further modification.
After modifications, the display will return to pressure-
temperature display mode.

Datakom DK-40 Specifications

Power

supply voltage (IN-COMM to IN-400V)	305 – 460 VAC
supply voltage (IN-COMM to IN-230V)	175 - 275 VAC
supply frequency	50 - 60 Hz nominal
power consumption	< 4 VA

Measurement Inputs

voltage input range (L-L)	20 - 520 V AC
voltage input range (L-N)	10 - 300 V AC
frequency input range	30 - 100 Hz

Accuracy

voltage accuracy	0.5% + 1 digit
frequency accuracy	0.5% + 1 digit
voltage burden	< 0.1 VA per phase

Relay Outputs

relay output current	5 A
relay output voltage	250 V AC
external switch resistance	< 3 K-ohms

Inputs

pressure input range	4-20 mA (optional 0-10 V)
temperature input range	1000-5000 ohms
motor PTC input alarm threshold	2000 ohms

Operating Environment

operating temperature	-30°C to +80°C (-22°F to +176°F)
storage temperature	-40°C to +80°C (-40°F to +176°F)
maximum humidity	95% non-condensing

Physical Characteristics

degree of protection (front panel)	IP 54
degree of protection (back panel)	IP 30
dimensions	134x107x54 mm (WxHxD)
