DK-40 USER MANUAL V2.6 (02.08.2011)
K13D01-E - 41 -
10.3. ALARMS-WARNINGS-SERVICE REQUESTS
The ALARM record is 32 bits. Each bit indicates the existence of an alarm.
BIT
NO:
DESCRIPTION
1 Low Voltage Alarm
2 High Voltage Alarm
3 Low Frequency Alarm
4 High Frequency Alarm
5 Thermal Motor Switch Open
6 Thermal Fan Switch Open
7 High Temperature Alarm
8 Temperature Sensor Fail
9 Low Temperature Alarm
10 Security Pressure Switch Open
11 High Pressure Alarm
12 Pressure Transducer Fail
13 Emergency Stop
14 -
15 Motor PTC Sensor Fail
16 Motor PTC High Temperature Alarm
17 Motor PTC Low Temperature Alarm
18 Phase Sequence Fail Alarm
19 Air Filter Clogged
20 Temperature Sensor 2 Fail
21 High Temperature 2 Alarm
22 Low Temperature 2 Alarm
23 Pressure Transducer 2 Fail
24 High Pressure 2 Alarm
25 Differential Pressure Alarm
26-32 -
The warning register is 16 bits. Each bit indicates the existence of a warning.
BIT
NO:
DESCRIPTION
1 Remote Stop
2 Remote Start
3 Parameter out of limits
4 High Temperature
5 No Stop since 1 Hour
6 Start waits separator pressure drop
7 Differential temperature
8-16 -
