CBX800 INSTALLATION MANUAL
6
OPENING THE CBX800
To install the CBX800 or during normal maintenance, it is necessary to open it by unscrewing the four cover
screws:
CAUTION
The CBX800 must be disconnected from the power supply during this operation.
ACCESS TO INTERNAL PARTS
To make installation and replacement easier, the CBX800 is made up of three parts:
1) the body of the device containing all electronic components and optional boards
2) the transparent removable cover for inspection and for easy access to spring clamps and internal
modules
3) the removable front connector panel providing easy access to the optional interface modules
Figure 2 – CBX800 Front Connector Panel

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Datalogic CBX800 and is the answer not in the manual?

Datalogic CBX800 Specifications

General IconGeneral
Product colorBlack, Blue, Grey
LED indicatorsYes
Housing material-
Protection featuresShock resistant, Vibration proof
International Protection (IP) codeIP65
Input voltage10/30 V
Power source typeDC
Power consumption (typical)2.5 W
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)0 - 90 %
TypeBarcode module bar barcode readers
Scanner type1D/2D
Connectivity technologyWired
Harmonized System (HS) code84716070
Weight and Dimensions IconWeight and Dimensions
Depth137 mm
Width128 mm
Height62 mm
Weight360 g
