GENERAL FEATURES
2
The LT-210 Mini Spot Lighting System provides a high intensity light source designed for the
following applications:
• with uneven, noisy and scratched surfaces
• where dot peening or laser etching codes are directly marked onto metal surfaces or
PCBs and need to be highlighted. Here the use of more than one Spot Light can remove
any shadowing effect.
• in the presence of highly reflective surfaces (metal, glass, etc.) causing direct reflections.
Low light path to surface angles strongly reduce direct reflections.
Figure 25 - LT-210 Mini Spot Lighting System
The LT-300 Ring Lighting System is designed for reading codes produced by Dot Peening or
Laser Etching on flat, reflective parts.
Figure 26 - LT-300 Ring Lighting System
The LT-314 45° Dark Field Ring Lighting System is designed for reading codes produced by
Dot Peening or Laser Etching on flat, reflective parts.
Figure 27 - LT-314 45° Dark Field Ring Lighting System
21
