SOFTWARE CONFIGURATION
8
8.3 STARTUP
After completing the mechanical and electrical connections to Matrix-2000™, you can begin
software configuration as follows:
1. Power on the Matrix-2000™ reader. Wait for the reader startup. The system bootstrap
requires a few seconds to be completed. The reader automatically enters Run Mode.
2. Run the VisiSet™ program.
3. Press Connect on the VisiSet™ menu bar. The PC will automatically connect to the
Matrix-2000™ reader.
Upon connection, Matrix-2000™ exits Run Mode and displays the Main Menu on
VisiSet™ with all the commands necessary to monitor your reader's performance. You
can select these commands using the mouse or by pressing the key corresponding to the
letter shown on the button. See Figure 94.
Menu Bar
Terminal
Window
Commands
Window
Status Bar
Figure 94 - Main Window
69
