MATRIX-2000™ REFERENCE MANUAL
3
73
[2.87]
121
[4.76]
57
[2.24]
mm
[inch]
73
[2.87]
Ø
4
.
2
[
Ø
0
.
1
7
]
15
[0.59]
37
[1.46]
4.2
[0.17]
95
[3.74]
47.5
[1.87]
Ø
8
.
2
[
Ø
0
.
3
2
]
47.5
[1.87]
95
[3.74]
2
[0.08]
mm
[inch]
Figure 35 - Overall dimensions - 90° model Figure 36 - Mounting Bracket Overall Dimensions
3.2.1 Mounting Matrix-2000™
Using the Matrix-2000™ mounting bracket you can obtain vertical shift and rotation of the
reader as shown in the diagram below:
Figure 37 - Positioning with Mounting Brackets
