MATRIX-2000™ REFERENCE MANUAL
8
8 SOFTWARE CONFIGURATION
Software configuration of your Matrix-2000™ for static reading or simple code reading
applications can be accomplished by the Rapid Configuration procedure using the onboard
keypad Autolearning Configuration (which requires no external configuration program) or by
using the VisiSet™ Autolearning Wizard for easy setup. These procedures are described in
chapter 1.
For all other applications use VisiSet™ through the reader serial ports (or Ethernet port for
Matrix-21XX models only).
NOTE
Before using VisiSet™ via Ethernet, it is necessary to configure Matrix-
2000™ Ethernet port parameters using VisiSet™ via Main or Auxiliary serial
port (for further details refer to the VisiSet™ Help on line).
8.1 VISISET™ SYSTEM REQUIREMENTS
To install and run VisiSet™ you should have a Laptop or PC that meets or exceeds the
following:
• Pentium processor
• Win 98/2000, NT 4.0, XP or Vista
• 32 MB Ram
• 5 MB free HD space
• one free RS232 serial port with 115 Kbaud
• SVGA board (800x600) or better using more than 256 colors
8.2 INSTALLING VISISET™
To install VisiSet™, proceed as follows:
1. Turn on the Laptop or PC that will be used for configuration (connected to the Matrix-
2000™ communication ports).
2. After Windows finishes booting, insert the CD-ROM provided.
3. Launch VisiSet™ installation by clicking
Install.
4. Follow the instructions in the installation procedure.
68
