Datalogic Compact 2D Reader Matrix-2000 User Manual

TYPICAL LAYOUTS
6
When using a Local Area Network (LAN), one or more Matrix-21XXs can be connected to the
network by using straight through cables:
Matrix-2000™
CBX
Host
NETWORK
Powe
r
CAB-Sxx
1
2
3
 Ethernet Interface (Straight Through Cables)
 Auxiliary Serial Interface (Local Echo) (RS232)
 External Trigger (for One Shot or Phase Mode)
Figure 92 - Ethernet Network Layout
63
